Vibrator :

Dynamic rated force

maximum 9.8N

Frequency range

80 Hz、500 Hz (build in)

5 Hz – 5 kHz (with external source)

Max Displacement

5mm P-P

Movable mass

< 75 g

Flexure stiffness

400 g/mm

Distortion factor

< 2%, 80 Hz, 500 Hz 10 m/s²

Vibration table

f25mm with M6 P=1

Option：M5 、 10-32UNF-2B

Vibration Meter :

Acceleration range

0 - 199.9 m/s², resolution 0.1 m/s²

Displacement range

0 - 1.999 mmP-P, resolution 1 μmP-P

Accuracy

< 3% (80 Hz, 10 m/s2, 25 °C )

Frequency response

5 Hz ~ 5 kHz

Monitor output

AC ±2V F.S.

Other specifications :

Ambient temperature

-20°C ~ 50°C

Power supply

AC100V±10V 50Hz/60Hz max 1A

Dimension

(W)120×(H)200×(D)200 mm

Weight
