Model

GTDL-620

GTDL-620-S(static)

Number of Channel

8, 16, 24, 32, 40, 48, 56, 64 channel

Measure Hz

1,000 Hz

Bridge exciting time: 50 msec

Connector for sensor

5p Screw connector or TAJIMI

Input Sensor

- 1Gage & 2Gage: 120 Ω, 350 Ω

- 4 Gage Bridge Sensor: 0.5 mV/V ~ 100 mV/V - Potentiometer Sensor

- Pt100 temperature sensor

- Voltage: 10 V

Strain Input Range

10,000, 100,000, 1,000,000 X 10^-6 strain

Low Pass Filter

10 Hz, 100 Hz, 1 KHz, Pass Program Selectable

Interface

USB

Program

Multiscan S/W & Multiload S/W

Dimension

500(W)*190(H)*380(D)mm

Power

AC 220 V, 50~60 Hz or DC 12 V
