Model

GTDL-610

Number of Channel

4, 8, 12, 16, 20, 24, 28, 32 channel

Display & data memory

10.2" TFT Touchable LCD

16G SD Data Memory, USB Memory Stick Port(EXT)

Measure frequency

1,000 Hz

Connector for sensor

5p Screw connector or TAJIMI

Input Sensor

- 1Gage & 2Gage : 120 Ω, 350 Ω

- 4 Gage Bridge Sensor : 0.5 mV/V ~ 100 mV/V

- Potentiometer Sensor

- Pt100 temperature sensor , thermocouple temperature sensor J, K, T, E, R, S

- Voltage: 10V

Strain Input Range

10,000, 100,000, 1,000,000 X 10^-6 strain

Low Pass Filter

10Hz, 100Hz, 1KHz, Pass Program Selectable

Bridge excitation

DC 2 V, 5 V, 10 V Program Selectable

Interface

USB

Program

Multiscan S/W & Multiload S/W

Dimension

450(W)*180(H)*310(D)mm

Power

AC 220 V, 50~60 Hz
