Model

GTDL-350

GTDL-360

Number of Channel

4, 8, 12, 16 channel

4, 8, 12, 16, 20, 24, 28, 32 channel

Measure Hz

1,000 Hz

Connector for sensor

5p Screw connector or TAJIMI

Input Sensor

- 1Gage & 2Gage : 120 Ω, 350 Ω

- 4 Gage Bridge Sensor : 0.5 mV/V ~ 100 mV/V

- Potentiometer Sensor

- Pt100 temperature sensor, thermocouple temperature sensor J, K, T, E, R, S

- Voltage: 10V

Strain Input Range

10,000, 100,000, 1,000,000 X 10^-6 strain

Low Pass Filter

10 Hz, 100 Hz, 1 KHz, Pass Program Selectable

Interface

USB

Program

Multiscan S/W & Multiload S/W

Dimension

270(W)*190(H)*270(D)mm

360(W)*190(H)*270(D)mm

Power

AC 220 V, 50~60 Hz
